As an ideal entry product to digital black & white printing, the bizhub PRO 1100 paves the way for new business opportunities. With it, you’ll accomplish more print jobs in the shop and meet tightest deadlines with ease. You can thus diversify and grow your business and are looking into a bright future. The bizhub PRO 1100 is the key for your success. Use it as your stepping stone to steady and robust profitability. Offering complete and dependable productivity, the bizhub PRO 1100 stands for your and your customers’ ease of mind. Further to this, you’ll also reduce your personal ecological footprint with the bizhub PRO 1100’s range of green technologies: Konica Minolta consistently promotes sustainable product development and integrates environmental and social perspectives into its business strategies.
bizhub Pro B1100
Key Features
Functionalities
Spesifications
Media
Key Features
-
- Production speed:100 A4 or 55 A3 pages per minute
- High print quality: 1,200 x 1,200 dpi resolution
- Modular paper feeding and versatile finishing options
- One-pass duplex scanning
- Black & white production speed of 100 A4 or 55 A3 pages per minute, paired with high RIP performance for outstanding productivity
- High print quality with 1,200 x 1,200 dpi resolution and LED print head
- Media weights between 40 and 300 gsm (optional 350 gsm) in combination with intelligent paper catalogue with mixplex/mixmedia functionality
- Modular paper feeding and versatile finishing options
- One-pass duplex scanning ensures processing of up to 180 ipm in colour and black and white
Functionalities
Printer Specifications
| Print speed A4 | 100 ppm |
|---|---|
| Print speed A3 | 56 ppm |
| Print speed SRA3 | 53 ppm |
System Specifications
| Paper weight | 40-300 gsm (350 gsm optional*) |
|---|---|
| Duplex unit | Non-stack type; 40-300 gsm |
| Paper sizes | Standard: Min.: 182 x 139 mm Max.: 324 x 463 mm Optional: Min.: 95 x 139 mm* Max.: 324 x 483 mm** |
| Maximum image area | 314 x 463 mm (up to 483 mm** optional) |
| Maximum paper input capacity | Standard: 3,000 sheets Max.: 9,000 sheets |
| Maximum paper output capacity | Max.: 4,200 sheets |
| Warm-up time | Less than 390 sec. |
| Main unit dimensions (W x D x H) | 990 x 910 x 1,454 mm |
| Main unit weight | 340 kg |
Scanner Specifications
| Scan speed A4 | Up to 180 opm |
|---|---|
| Scan resolution | 600 x 600 dpi |
| Scan modes | Scan to HDD; Scan to FTP; Scan to PC; Scan to email; Scan to WebDAV; Scan to USB Memory; HDD to FTP/SMB/WebDAV |
| Scan formats | TIFF; PDF; Encrypted PDF; Compact PDF; XPS; JPEG |
Copier Specifications
| Gradations | 256 gradations |
|---|---|
| FCOT | Less than 3.4 sec. (A4 LEF) |
| Magnification | 25-400%, in 0,1% steps |
| Multiple copies | 1 – 9,999 |
Accessories Specifications
| Large capacity tray | A4: LU-411 A3: LU-412 |
|---|---|
| Multi bypass tray | MB-507 |
| Paper feed unit | Paper feed unit PF-709 |
| Multi (GBC) punching unit | Multi (GBC) punching unit GP-501 Multi punching of A4 sheets User replaceable die sets for: Velo bind, plastic comb, wire bind, colour coil, pro click Paper weight: 75 – 216 gsm |
| Auto ring binder | Auto ring binder GP-502 Stacking, punching and binding of books, up to 102 sheets; self-adjusting bind elements (one size fits all); paper weight: content 75-120 gsm; cover 163-216 gsm |
| Booklet finisher | Saddle stitching kit SD-510 (for FS-532) Booklet making of up to 20 sheets (80 images) Saddle stitching Cover sheets from 50 to 300gsm Output tray for booklets Multi-letter fold-in (up to 3 sheets) Multi-half fold (up to 5 sheets) |
| Post inserter | Post insertion unit PI-502 (for FS-532) Insertion of pre-printed sheets PI trays for 200 sheets each |
| Punch kit | Punch kit PK-522 (for FS-532) Punching (2 and 4 holes selectable) |
| Staple finisher | Stapling unit FS-532 Stapling of up to 100 sheets 2-point and corner stapling Variable staple length (cutting mechanism) Output for up to 4,200 sheets (A4) Sub tray for up to 200 sheets Auto-shift sorting and grouping |
| Removable HDD kit | RH-101 HD-523 |
Controller Specifications
- All specifications relating to paper capacity refer to A4-size paper of 80 gsm quality.
- All specifications relating to scanning, copying or printing speeds refer to A4-size paper that is scanned, copied or printed crosswise in multipage, simplex mode.
- The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
- Some of the product illustrations contain optional accessories.
- Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
- Konica Minolta does not warrant that all specifications mentioned will be error-free.
- Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
- All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
Spesifications
Printer Specifications
| Print speed A4 | 100 ppm |
|---|---|
| Print speed A3 | 56 ppm |
| Print speed SRA3 | 53 ppm |
System Specifications
| Paper weight | 40-300 gsm (350 gsm optional*) |
|---|---|
| Duplex unit | Non-stack type; 40-300 gsm |
| Paper sizes | Standard: Min.: 182 x 139 mm Max.: 324 x 463 mm Optional: Min.: 95 x 139 mm* Max.: 324 x 483 mm** |
| Maximum image area | 314 x 463 mm (up to 483 mm** optional) |
| Maximum paper input capacity | Standard: 3,000 sheets Max.: 9,000 sheets |
| Maximum paper output capacity | Max.: 4,200 sheets |
| Warm-up time | Less than 390 sec. |
| Main unit dimensions (W x D x H) | 990 x 910 x 1,454 mm |
| Main unit weight | 340 kg |
Scanner Specifications
| Scan speed A4 | Up to 180 opm |
|---|---|
| Scan resolution | 600 x 600 dpi |
| Scan modes | Scan to HDD; Scan to FTP; Scan to PC; Scan to email; Scan to WebDAV; Scan to USB Memory; HDD to FTP/SMB/WebDAV |
| Scan formats | TIFF; PDF; Encrypted PDF; Compact PDF; XPS; JPEG |
Copier Specifications
| Gradations | 256 gradations |
|---|---|
| FCOT | Less than 3.4 sec. (A4 LEF) |
| Magnification | 25-400%, in 0,1% steps |
| Multiple copies | 1 – 9,999 |
Accessories Specifications
| Large capacity tray | A4: LU-411 A3: LU-412 |
|---|---|
| Multi bypass tray | MB-507 |
| Paper feed unit | Paper feed unit PF-709 |
| Multi (GBC) punching unit | Multi (GBC) punching unit GP-501 Multi punching of A4 sheets User replaceable die sets for: Velo bind, plastic comb, wire bind, colour coil, pro click Paper weight: 75 – 216 gsm |
| Auto ring binder | Auto ring binder GP-502 Stacking, punching and binding of books, up to 102 sheets; self-adjusting bind elements (one size fits all); paper weight: content 75-120 gsm; cover 163-216 gsm |
| Booklet finisher | Saddle stitching kit SD-510 (for FS-532) Booklet making of up to 20 sheets (80 images) Saddle stitching Cover sheets from 50 to 300gsm Output tray for booklets Multi-letter fold-in (up to 3 sheets) Multi-half fold (up to 5 sheets) |
| Post inserter | Post insertion unit PI-502 (for FS-532) Insertion of pre-printed sheets PI trays for 200 sheets each |
| Punch kit | Punch kit PK-522 (for FS-532) Punching (2 and 4 holes selectable) |
| Staple finisher | Stapling unit FS-532 Stapling of up to 100 sheets 2-point and corner stapling Variable staple length (cutting mechanism) Output for up to 4,200 sheets (A4) Sub tray for up to 200 sheets Auto-shift sorting and grouping |
| Removable HDD kit | RH-101 HD-523 |
Controller Specifications
- All specifications relating to paper capacity refer to A4-size paper of 80 gsm quality.
- All specifications relating to scanning, copying or printing speeds refer to A4-size paper that is scanned, copied or printed crosswise in multipage, simplex mode.
- The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
- Some of the product illustrations contain optional accessories.
- Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
- Konica Minolta does not warrant that all specifications mentioned will be error-free.
- Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
- All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
